The use of aluminum fuel tanker trailer can not only recover the investment cost in a short time but also create more economic income and comprehensive benefits than carbon steel tank trucks. It is indeed the best choice for refined oil transportation equipment.
Aluminum semi trailers for sale are designed with safety and intelligence, and are mainly used for the transportation of refined oil, gasoline, diesel and gasoline petroleum products. Its design has the following advantages:
The 54,000 litres aluminum semi trailer for sale with low center of gravity design adopts square and circular sections, the center of gravity is reduced by 100mm for the same cross-sectional area, and the roll angle is increased to 30°>23° (standard value), effectively preventing rollover.
54,000 Litres Aluminum Fuel Tanker Trailer Price for Sale In Nigeria
54,000 Litres Aluminum Fuel Tanker Trailer Price for Sale In Nigeria
54,000 Litres Aluminum Fuel Tanker Trailer Price for Sale In Nigeria
Dimension: 12000mmx2490mm x3990mm
Aluminium Fuel Tank Trailer Total volume: 54000 liters
Tank Body Material: 5mm
Aluminium Fuel Tank Trailer End plate: 5mm
Manhole Cover: Aluminum alloy
Aluminium Fuel Tank Trailer Discharging Valve: Diameter is 3 or 4 inch
Compartments: Single Compartments
Discharging Pipe: 4 inch rubber hose,2pcs,6m/each
Cat Walk: With (common model or special design)
Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material
Axle: 3 axles,13T, FUWA brand
Landing Gear: JOST(D200T) or China brand 28T
Kingpin: JOST 2.0 or 3.5 inch bolt-in king pin
Suspension: Mechanical suspension
Leaf Spring: 90(w)mmx13(thickness)x10layers or 10mm x12mmx12 layers
Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tank
Rim: 9.00-22.5/8.00-20/8.5-20 Chinese brand
Tire: 12.00R22.5
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layer of top coats.
Accessories: One standard tool box
The aluminum fuel tank trailer tank body is welded by the biggest tank-producing machine and advanced longitudinal welding technology is adopted. The weld is very smooth and has no defects, which promises it can be used for more than 10 years. Aluminium fuel tank trailer adopts 25 tons of landing gear.
Aluminium fuel tank trailer uses enhanced suspension, whose thickness is 8 mm and the diameter of the kin pin is 70 mm.
Aluminium fuel tank trailer adopts 13 tons of axles, and 16 tons brake lining, which makes the trailer have a short brake distance to promise the trailer is safer.
Through this video, you can learn about different types of fuel tanker trailers, as well as the process, testing, packaging and customer feedback, etc.
